Acrodisc™ PVDF syringe filter, 0.45 µm, 13 mm, minispike outlet, 1000/pk

Acrodisc™ PVDF syringe filters, a Pall Life Sciences product, can be used for both aqueous and non-aggressive solvent-based sample filtration applications.

• Useful for a wide range of applications, including aggressive and non-aggressive solvent-based mobile phase.
• Reduces experimental variables. HPLC certified for low levels of UV-absorbing extractables.
• Protects columns and instrumentation against particulate build up.
• 13 mm device with minispike configuration offers low hold-up and easy filtration into autosampler vials.

Specifications:

• Bubble Point (IPA): ≥ 9 psi
• Connections: Female threaded Luer inlet, Minispike outlet
• Effective filtration area: 1.0 cm²
• Filter media: Hydrophilic polyvinylidene fluoride (PVDF)
• Housing material: Polypropylene
• Liquid Flow Rate (IPA): ≥ 13 mL/min @ 45 psi
• Maximum Operating Temperature:  55°C (131°F) @ 2.1 bar (210 kPa, 30 psi)
• Maximum operating pressure: 3.5 bar (350 kPa, 50 psi)
• Sample volume: < 10 mL
• Typical Hold-up volume: < 40 µL
