EXP® Ti-REX™ 10-32 Fitting/Adapter with PEEK Sleeves for 360 µm Tubing, 2/pk

EXP® Ti-REX™ 10-32 Fitting/Adapter with PEEK Sleeves for 360 µm Tubing, 2/pk

SKU: M152405532
Available Quantity : 0

Meet the EXP Ti-REX Fittings - a new, versatile approach to UHPLC connections for any 10-32 port. Utilizing bottom-of-the-port PEEK sealing, combined with EXP Titanium Hybrid Ferrule technology, the Ti-REX family offers robust, leak-free, cost-efficient solutions. The patented inverted geometric design firmly compresses the PEEK sleeve of the PEEKsil or fused silica tubing against the tube stop of any instrument port, creating a true zero-dead-volume (ZDV) connection without fracturing the fused silica. Ti-REX Fittings can be purchased with a 0.5 µm frit embedded in the tip to create an integral filter or capillary column end-fitting for standard 1/16” tubing ports

  • Rated hand-tight up to 21,000psi+ (1,500 bar+)
  • Robust one-piece design intended for many repeat uses
  • Create custom fitting sets, sample loops, capillary column end-fittings, etc.
  • Zero-dead-volume (ZDV) connections without the risk of fracturing fused silica tubing or overtightening
  • Universal design - fits any 10-32 port
  • Use with any 1/32" or 360um OD tubing
  • Leak prevention - does not 'point load'
  • PEEK wetted material for biocompatibility
  • Easily fits into tight spaces
  • Significant cost savings (20-30% less than alternatives)

Includes Fittings, PEEK Sleeves and EXP TI-REX Drive
