50 mL, Gastight Syringe, Bubble Free Prime (BFP, 5/16"-28)

Hamilton's  1000 series, Gastight, Bubble Free Prime #1050 Bubble Free Prime (BFP, 5/16"-28) Syringes with X-Style plunger features a conical plunger tip which extends through the threaded termination of the syringe and into the valve. This unique design expels the air from the syringe and valve, decreasing the number of cycles required to prime the fluid path. This series of syringes are ideal for dispensing both liquids and gases. They have a polymer plunger tip that creates a leak-free seal.  Hamilton syringes ensure an accuracy of ± 1%, superior durability, and are manufactured with the highest quality chemically resistant materials.

• A white polymer plunger tip effectively wipes the glass barrel, creating a leak-free seal.
• Ensures a Gastight performance, suitable for liquids and gases.
• Features a conical plunger tip that extends through the 5/16" -28 threaded termination and into the valve.
• This unique zero dead volume design expels air from the system and reduces the priming cycles required to eliminate air bubbles.

• Volume:  50 mL
• Syringe Type:  Gastight, Bubble Free Prime
• Syringe Series:  1000
• Termination:  Bubble Free Prime™ (BFP, 5/16"-28)
• Needle:  No Needle Available
• Plunger Style:  X-Style
• Fluid Path:  Borosilicate glass, PTFE, PFA
• Autoclavable:  No
• Gas Sterilizable:  Yes
• Pressure:  100 psig (6.9 bar)
• Maximum Operating Temperature:  80°C / 176°F
• Minimum Operating Temperature:  10°C / 50°F
• Barrel Inner Diameter:  1.28 inches (32.6 mm)
• Barrel Outer Diameter:  1.45 inches (36.9 mm)
• Plunger Tip Material:  PTFE
• Stroke Length:  60 mm
