YMC-Pack Diol-NP Analytical Guard Cartridge, 120 Å, 5 um, 20 mm x 3.0 mm ID, 5/pk

YMC-Pack Diol-NP is a versatile alternative to silica for normal phase separations and provides much better reproducibility when compared to bare silica material. It shows typical normal phase retention behavior when used with low-polarity mobile phases due to hydroxyl groups on the surface of the stationary phase acting as polar groups.

Hydrogen bonding with the Diol-NP layer is not as strong as with silanols on a bare silica surface. As a result, the bonded layer’s hydroxyl groups provide good selectivity without excessive retention. YMC-Pack Diol-NP can also be used in HILIC-mode with organic/water mobile phases.

Features & Benefits:

• Improved peak shape versus bare silica
• Good selectivity without excessive retention
• High product recovery
• Excellent bonded-phase reproducibility
• Long column lifetime
• High loading with prep material

• Stationary Phase: dihydroxypropyl
(USP L20)
• Bonding: Monomeric
• Mode: Normal Phase
• Particle Size: 5 µm
• Pore Size: 120 Å
• pH Range: 2 – 7.5
• Temperature Upper Limit: 50 °C
• Temperature Recommended Range: 20 – 40 °C

.**Requires Holder YXPGCHP2
